RP-Cut VR-4004 (NC Controller) – Hydraulic Guillotine Shearing Machine
The RP-Cut VR-4004 is a hydraulic guillotine shearing machine fitted with an NC servo back gauge controller, built for fast, accurate sheet metal cutting in high-volume production environments. With a 4000mm cutting length and the capacity to shear mild steel up to 4mm and stainless steel up to 3mm, it is engineered for fabrication shops, sheet metal processors, and metal stockists that need repeatable cut lengths without manual gauge adjustment.
- Starting from ₹ 11,00,000
Key Features of RP-Cut VR-4004 (NC Controller) Shearing Machine
NC Servo Back Gauge
Automated X-axis positioning via servo motor and drive delivers precise, repeatable cut lengths and cuts setup time between jobs
7″ Touch Display with Auto Program Function
Store and recall cutting programs on a Delta/Schneider PLC system, with stroke counter and Inch/Single/Auto cycle modes
Automatic Rake Angle Adjustment
Hydraulically adjusts the blade's cutting angle to handle varying sheet thicknesses without twist distortion
Four-Edge Interchangeable Blade
HCHCr/OHNS-grade blade with four usable cutting edges, easily replaced to keep cuts burr-free over a long service life
Heavy-Duty Hold-Down System
20 hydraulic hold-downs deliver 3200kg holding force across the full sheet width, preventing slippage regardless of thickness variation
Stress-Relieved Steel Frame
IS-2062 graded rolled steel construction, furnace stress-relieved and machined after stress relieving for lasting cutting accuracy
Key Features of RCP-10T C-Frame Power Press
Bending Capacity
65 Ton – designed for mid-range industrial sheet metal bending
Rear Cylinder Hydraulic System
Uniform ram pressure for consistent, accurate bending results
Variable Stroke Control
Adjustable ram stroke with limit switch for precise angle setting
Durable and Efficient
Heavy-duty steel-fabricated frame built for continuous production use
Easy Maintenance
Compact hydraulic block design reduces leakage and lowers service costs
RP-Cut VR-4004 Specifications
Specification
Details
Machine Size
4000 x 4 mm
Blade Length
4065 mm
M.S. Cutting (Min/Max)
3 / 4 mm
S.S. Cutting (Min/Max)
2 / 3 mm
Normal Rake Angle
1.37°
Specification
Details
Rake Angle Range
0.5° – 3°
Stroke Per Minute (Min/Max)
12 / 6
Hold Downs
20 Nos.
Holding Force
3200 Kgs.
Motor H.P.
7.5 HP
Specification
Details
Tonnage
65
Machine Size
2500 x 3
Table Length
175
Stroke LengthClear Pass
2000
Ram Stroke
125
Open Height
330
Throat Depth
200
Motor HP
5
Speed(Advance Working Return)
25-6-50
Buy RP-Cut VR-4004 Shearing Machine Online
- Starting from ₹ 11,00,000
Applications of RP-Cut VR-4004
- Sheet metal fabrication & job shops
- Iron and steel processing
- Boiler and pressure vessel manufacturing
- Ship building
- Automotive component manufacturing
- Electrical panel & enclosure manufacturing
- Steel furniture manufacturing
- Metal stockists & steel service centers
- HVAC ductwork manufacturing
- Construction & structural steel fabrication
- Agricultural equipment manufacturing
- Railway coach & wagon fabrication
- Tank & silo manufacturing
- General engineering workshops
Why Choose Rajesh RP-Cut VR-4004?
Proven Engineering
Years of experience in manufacturing press machines
Made in India
Designed to meet international standards
Performance-Oriented
Ensures consistent output in demanding industrial settings
After-Sales Support
Nationwide support and service for smooth operation
What is the Price of the RP-Cut VR-4004 (NC Controller) Shearing Machine?
Get the best quote. Our team will guide you through pricing, delivery schedules, and any customization options available.
